Facility
CNC Machine
COSMOS-CVM-640
| Model Number | CVM-640 |
| Z – Axis Travel | 500 mm |
| X – Axis Travel | 650 mm |
| Y – Axis Travel | 450 mm |
| Brand | Cosmos |
| Table Dimension | 800 x 450 mm |
| Maximum Load | 400 Kg |
| Net Weight ( With Atc ) | 4500 Kg |
| Power Capacity | 20 KVA |
| Total M/C | 3 |
| Model Number | CVM-640 |
| Z – Axis Travel | 500 mm |
| X – Axis Travel | 650 mm |
| Y – Axis Travel | 450 mm |
| 4th Axis Rotary 200mm | |
| Brand | Cosmos |
| Table Dimension | 800 x 450 mm |
| Maximum Load | 400 Kg |
| Net Weight ( With Atc ) | 4500 Kg |
| Power Capacity | 20 KVA |
| Total M/C | 3 |
COSMOS-CVM-640 ROTARY
Cosmos CVM 800
| Model Number | CVM-800 |
| Z – Axis Travel | 500 mm |
| X – Axis Travel | 500 mm |
| Y – Axis Travel | 500 mm |
| Brand | Cosmos |
| Table Size | 1000×500 mm |
| Maximum Load | 600 Kg |
| Spindle Speed | 8000rpm Kg |
| Mitsubishi Motor Power | 11/15/18.5 kW |
| Spindle Taper | BBT 40 |
| Rapid Traverse Rate | 36(48) m/min |
| Cutting Feed Rate | 10 m/min |
| Tool Nos. Capacity | 30 |
| Total M/C | 2 |
VTL Machine
| Table Diameter | 3200 mm |
| Swing | 3600 mm |
| Max. Work Piece Height | 2000 mm |
| Max Table Loading | 20 Ton |
| Max. Ram Travel | 1500 mm |
| Max. Horizontal Travel Of Carriage | 2000 mm |
| Carriage Inclination Angle | 30 degree |
| Carriage Feeds Number | 16 |
| Carriages Feeds Range | 0.09 – 16 mm/rev |
| Feeds Of Traversal Beam | 360 mm/min |
| Max. Distance Between Ram’s Axis | 360 mm |
| Distance Between Table And Ram | 0 – 1780 mm |
| Distance Between Table & Lower Surface Of Traversal Beam | 400 – 1640 mm |
| Revolution Speeds Number | 18 |
| Table Speeds | 1.25-63 RPM |
| Main Engine Power | 55 KW |
CNC VTL Machine3.2 mtr
Description:
Machine Type: 3200mm3600mm CNC VTL Machine
Machine Make: StankoRussian Sedin
Features: Easy Installation, Pocket friendly prices, Minimum Maintenance.
Polishing
Description:
Machine Type: 3200mm3600mm CNC VTL Machine
Machine Make: StankoRussian Sedin
Features: Easy Installation, Pocket friendly prices, Minimum Maintenance.
Vibro Finishing
- Vibro Finishing
- Machine 300 Litres
- Capacity With Pu
- Lining And Manual
- Separation
- 01 Nos Machine
- 200 Kg Ceramic Deburring
- Media, 20 Kg Chemical
- 4 Nos Rubber Pad
- 1 Nos Motor Starter
Shot Peening
The system consists of a cabinet type blasting machine with LHS side & R.H.S hinged door. The cabinet is provided with front hand holes for manoeuvring purpose and viewing window. A motorized turntable is mounted inside the cabinet. A pressure pot is provided beneath the cabinet hopper. Dust created during blasting is sucked by the Dry Cartridge Element type dust collector.
Shot Peening & Glass Beeding
To provide manual blasting operation using pressure blaster for the generation of controlled and required roughness (Ra value) on the Components having maximum weight 200 Kgs using blasting media steel shot S70
Coating Process
Inspection
